ADJ
Saber Spot WW
Saber Spot WW
SKU: SAB605
Usually ships in 2-3 business days. Fill out a quote request and we'll check backorder status!
Couldn't load pickup availability
The Saber Spot WW is a compact Pinspot with a 15-Watt warm white LED. Features DMX-512, flicker-free operation, strobing, electronic dimming and has a 4-Button DMX display system on the rear panel. Its built-in ACL lens produces a razor sharp 4-degree beam angle.
In the Box:
- (1) Saber Spot WW
- (1) Locking Power Cable
- (1) 10° Frost Filter
- (1) 45° Frost Filter
- (1) O-ring for frost filter lens
Features:
- Light Source: 15W Warm White LED
- Beam Angle: 4° (optional 10° & 45° lenses included)
- Dimming: 0 - 100% with 5 selectable curves
- Refresh Rate: 3.6KHz
- Strobe: Variable
- Control Protocol: DMX & RDM
- IP Grade: IP20
Tech Specs
Optics:
Light Source Type: Warm White LED
Light Source Wattage: 15w
Minimum Beam Angle: 4.0°
Maximum Beam Angle: 45.0°
Control
DMX Channel Modes: 1 / 2
DMX 3-Pin Connectors?: Yes
DMX 5-Pin Connectors?: No
Physical:
Length: 3.5 in
Width: 6.75 in
Height: 3.5 in
Weight: 2.6 lb
Electrical
Voltage Range: 100 - 240 VAC 50/60Hz
Maximum Wattage: 15w
Power Cable Connector - Fixture Side: PowerCON
Main Power Connector on Included Cable: Edison
